IEC GIS RMU 개폐기

GIS Metal enclosed IEC standard medium-voltage RMU switchgear

General

XGN□-12/24 series fully insulated and fully enclosed inflatable metal switchgear, referred to as inflatable cabinet, also known as co-box type inflatable cabinet, sf6 inflatable cabinet, and fully insulated and fully enclosed inflatable cabinet. It is a set of fully enclosed switchgear. All the live parts are completely sealed in a 3.0mm thick stainless steel SF6 gas box. Multiple branch switches can be installed in one gas box, so that the switchgear is not affected by the environment. It truly realizes the functions of maintenance-free, reliable operation, unattended, etc. The inflatable cabinet unit adopts a modular design, which can be flexibly expanded and scientifically combined. It is a fully insulated and fully enclosed high-voltage switch cabinet.

Service environment
1. Air temperature: -25℃~+40℃
2. Humidity: Monthly average 95%; Daily average 90%.
3. Altitude:≤ 2500m
4. Ambient air not apparently polluted by corrosive and flammable gas, vapor, etc.
5. No frequent violent shake

The customer should offer the following information for the order:
1. Wiring diagram of Main circuit Loop and Special Technical Requirement;
2. Installation Arrangement Plan of switch panel;
3. Specification of components inside switch panel and the schematic diagram of auxiliary loop and control loop diagram.
4. Other written documents especially required.
5. SLD(Single Line Drawing)

Knkong Electric provides 11KV switchgear according to the customer's requirements, please send us the SLD then We could implement it 100%.11KV switchgear is our best-selling international product, with China's independently developed vacuum circuit breaker VS1 that allows us to compete with European products in the international market.
